For crafting your custom keyboard, these "Half Height" Low Profile MX key switches are compatible with standard MX layouts and solder-free sockets but are significantly shorter, for a slimmer build. Compared to standard "Cherry MX" compatible switches, which have 10mm above-board height, these have 7mm - but still have the 4mm actuator height. (The 'half height' comes from them having a remaining 3mm vs 6mm body height from the mounting plate to the actuation floor)

Like "MX Black" key switches, these have a smooth linear keystroke. They're basically like MX blacks, but 3mm shorter.

• Type: Linear
• Operating force: 70 gf ( /-10 gf)
• Pretravel: 1.2mm
• Total travel: 3.0 mm

• Use these with our , such as the  and the .
•  if you want to avoid soldering.
•  to snap right on.
